exercises/Day-1/PTBcolor.bmp

2.96 MiB

import struct
from PIL import Image
import numpy as np
class Bitmap(object):
def __init__(self, file_name: str = None):
pass
def _read_header(self, fp):
# reads the bitmap header information, should read the height and width into instance attributes
# You may get rid of all the unnecessary information stored there
pass
def _read_pixel_array(self, fp):
# reads the bitmap pixel data into an instance attribute KEEP data structur list(list(list))) as is, see below
pass
def get_pixel(self, x: int, y: int):
# returns a pixel in the form [r,g,b] = [int, int, int] at position (x,y)
pass
def set_pixel(self, x: int, y: int, rgb_index: int, value):
# sets a color of pixel at (x,y) to input value
pass
if __name__ == "__main__":
# Refactor the following code between the markers into a "Bitmap" Class using the skeleton above
# **************************** REFACTOR START **********************************************
# here we read the bitmap
bmp = open("./PTBcolor.bmp", 'rb')
print('Type:', bmp.read(2).decode())
print('Size: %s' % struct.unpack('I', bmp.read(4)))
print('Reserved 1: %s' % struct.unpack('H', bmp.read(2)))
print('Reserved 2: %s' % struct.unpack('H', bmp.read(2)))
# This is the offset to the pixel array
print('Offset: %s' % struct.unpack('I', bmp.read(4)))
print('DIB Header Size: %s' % struct.unpack('I', bmp.read(4)))
print('Width: %s' % struct.unpack('I', bmp.read(4)))
print('Height: %s' % struct.unpack('I', bmp.read(4)))
## Seek the offset position of the pixel array
## This is above output "Offset"
bmp.seek(54)
# We need to read pixels in as rows to later swap the order
# since BMP stores pixels starting at the bottom left.
bmp_pixel_array = []
row = []
pixel_index = 0
# this reads the pixels
# NOTE the hard coded image sizes (width=1300 and height=795)
while True:
if pixel_index == 1300:
pixel_index = 0
bmp_pixel_array.insert(0, row)
if len(row) != 1300:
raise Exception("Row length is not 1300 but " + str(len(row)))
row = []
pixel_index += 1
r_string = bmp.read(1)
g_string = bmp.read(1)
b_string = bmp.read(1)
if len(r_string) == 0:
# This is expected to happen when we've read everything.
if len(bmp_pixel_array) != 795:
print("Warning!!! Read to the end of the file at the correct sub-pixel (red) but we've not read 795 rows!")
break
if len(g_string) == 0:
print("Warning!!! Got 0 length string for green. Breaking.")
break
if len(b_string) == 0:
print("Warning!!! Got 0 length string for blue. Breaking.")
break
r = ord(r_string)
g = ord(g_string)
b = ord(b_string)
row.append([b, g, r])
bmp.close()
## **************************** REFACTOR END **********************************************
# CHECK CODE: You should not see any "Mismatch at index pair ..." lines
bmp = Bitmap("./PTBcolor.bmp")
print("Dims of bitmap: ({},{})".format(bmp.width, bmp.height))
# Test the naive implementation against the PIL library version
# this is for comparison
pil_img = Image.open("./PTBcolor.bmp")
pil_img_arr = np.array(pil_img)
for i in range(795):
for j in range(1300):
for rgb in range(3):
pil_pixel = pil_img.getpixel((j, -i))[rgb]
my_pixel = int(bmp_pixel_array[-i][j][rgb])
if pil_pixel != my_pixel:
print("Mismatch at index pair (x,y,c) = ({0}, {1}, {2}) : {3} != {4}".format(
i, j, rgb, pil_pixel, my_pixel))
import struct
from PIL import Image
import numpy as np
import abc
from collections import namedtuple
# TASK 1
# Use below very simple interface of a pixel in the Bitmap class
Pixel = namedtuple('Pixel', ['b', 'g', 'r'])
# TASK 2
# Complete below Interface (Trait) and use it (implement it) in Bitmap
class Addressable2D(object, metaclass=<EDIT HERE>):
@<EDIT HERE>
def get_at(self, x: int, y: int):
pass
@<EDIT HERE>
def set_at(self, x: int, y: int, data):
pass
@<EDIT HERE>
def get_width(self):
pass
@<EDIT HERE>
def get_height(self):
pass
class Bitmap(object):
def __init__(self, file_name: str = None):
self.width = None
self.height = None
self.bmp_file = file_name
self._pixel_array = None
if file_name is not None:
with open(self.bmp_file, 'rb') as file_handle:
self._read_header(file_handle)
self._read_pixel_array(file_handle)
def _read_header(self, fp):
# we do not need all the information here, just the x and y dimensions
# read 18 bytes to nirvana
_ = fp.read(18)
self.width = int(struct.unpack('I', fp.read(4))[0])
self.height = int(struct.unpack('I', fp.read(4))[0])
# set the file pointer to the beginning of the pixel array
fp.seek(54)
def _read_pixel_array(self, fp):
self._pixel_array = []
row = []
pixel_index = 0
# this reads the pixels
while True:
if pixel_index == self.width:
pixel_index = 0
self._pixel_array.insert(0, row)
if len(row) != self.width:
raise Exception("Row length is not {}} but ".format(self.width))
row = []
pixel_index += 1
r_string = fp.read(1)
g_string = fp.read(1)
b_string = fp.read(1)
if len(r_string) == 0:
# This is expected to happen when we've read everything.
if len(self._pixel_array) != self.height:
print(
"Warning!!! Read to the end of the file at the correct sub-pixel "
"(red) but we've not read {} rows but {}!".format(self.height, len(self._pixel_array)))
break
if len(g_string) == 0:
print("Warning!!! Got 0 length string for green. Breaking.")
break
if len(b_string) == 0:
print("Warning!!! Got 0 length string for blue. Breaking.")
break
r = ord(r_string)
g = ord(g_string)
b = ord(b_string)
# NOTE the order blue, green, red
row.append([b, g, r]) # <EDIT HERE>
def get_pixel(self, x: int, y: int):
return self._pixel_array[y][x]
def set_pixel_value(self, x: int, y: int, rgb_index: int, value):
self._pixel_array[y][x][rgb_index] = value
def set_pixel(self, x: int, y: int, pixel):
self._pixel_array[y][x] = pixel
if __name__ == "__main__":
# CHECK CODE: You should not see any "Mismatch at index pair ..." lines
bmp = Bitmap("./PTBcolor.bmp")
print("Dims of bitmap: ({},{})".format(bmp.width, bmp.height))
# Test the naive implementation against the PIL library version
# this is for comparison
pil_img = Image.open("./PTBcolor.bmp")
pil_img_arr = np.array(pil_img)
for i in range(795):
for j in range(1300):
for rgb in range(3):
pil_pixel = pil_img.getpixel((j, -i))[rgb]
my_pixel = bmp.get_pixel(j, -i)[rgb]
if pil_pixel != my_pixel:
print("Mismatch at index pair (x,y,c) = ({0}, {1}, {2}) : {3} != {4}".format(
i, j, rgb, pil_pixel, my_pixel))
import struct
from PIL import Image
import numpy as np
import copy
import typing
import abc
from collections import namedtuple
# here we define a better Pixel data structure
Pixel = namedtuple('Pixel', ['b', 'g', 'r'])
class Addressable2D(object, metaclass=abc.ABCMeta):
@abc.abstractmethod
def get_at(self, x: int, y: int):
pass
@abc.abstractmethod
def set_at(self, x: int, y: int, data):
pass
@abc.abstractmethod
def get_width(self):
pass
@abc.abstractmethod
def get_height(self):
pass
class Bitmap(Addressable2D):
def __init__(self, file_name: str = None):
self.width = None
self.height = None
self.bmp_file = file_name
self._pixel_array = None
if file_name is not None:
with open(self.bmp_file, 'rb') as file_handle:
self._read_header(file_handle)
self._read_pixel_array(file_handle)
def _read_header(self, fp):
# we do not need all the information here, just the x and y dimensions
# read 18 bytes to nirvana
_ = fp.read(18)
self.width = int(struct.unpack('I', fp.read(4))[0])
self.height = int(struct.unpack('I', fp.read(4))[0])
# set the file pointer to the beginning of the pixel array
fp.seek(54)
def _read_pixel_array(self, fp):
self._pixel_array = []
row = []
pixel_index = 0
# this reads the pixels
while True:
if pixel_index == self.width:
pixel_index = 0
self._pixel_array.insert(0, row)
if len(row) != self.width:
raise Exception("Row length is not {}} but ".format(self.width))
row = []
pixel_index += 1
r_string = fp.read(1)
g_string = fp.read(1)
b_string = fp.read(1)
if len(r_string) == 0:
# This is expected to happen when we've read everything.
if len(self._pixel_array) != self.height:
print(
"Warning!!! Read to the end of the file at the correct sub-pixel "
"(red) but we've not read {} rows but {}!".format(self.height, len(self._pixel_array)))
break
if len(g_string) == 0:
print("Warning!!! Got 0 length string for green. Breaking.")
break
if len(b_string) == 0:
print("Warning!!! Got 0 length string for blue. Breaking.")
break
r = ord(r_string)
g = ord(g_string)
b = ord(b_string)
row.append(Pixel(b, g, r))
def get_pixel(self, x: int, y: int) -> Pixel:
return self._pixel_array[y][x]
def set_pixel_value(self, x: int, y: int, rgb_index: int, value):
self._pixel_array[y][x][rgb_index] = value
def set_pixel(self, x: int, y: int, pixel: Pixel):
self._pixel_array[y][x] = pixel
def _init_pixel_array(self, width: int, height: int, color: typing.List = None):
assert color is not None and (isinstance(color, list) and len(color) == 3),\
"Invalid color array passed to _init_pixel_array, should contain 3 colors [r,g,b]. Passed {}".format(color)
if color is None:
use_color = [255, 255, 255]
else:
use_color = color
self.width = width
self. height = height
self._pixel_array = []
for j in range(height):
row = []
for i in range(width):
# NOTE: We need to copy the *list*, otherwise we store the same reference in all places!
c = copy.deepcopy(use_color)
row.append(c)
self._pixel_array.insert(0, row)
@classmethod
def from_dims(cls, width: int, height: int):
this_bmp = cls(file_name=None)
this_bmp._init_pixel_array(width, height, color=[255, 255, 255])
return this_bmp
@classmethod
def from_other(cls, other: 'Bitmap'):
this_bmp = copy.deepcopy(other)
return this_bmp
def get_at(self, x: int, y: int):
return self.get_pixel(x, y)
def set_at(self, x: int, y: int, pixel):
self.set_pixel(x, y, pixel)
def get_width(self):
return self.width
def get_height(self):
return self.height
## <EDIT HERE> Write an interface for a Filter use ABC!
class FilterTrait(object):
pass
## <EDIT HERE> Use above interface here
class DirectNeighborSmoother(<EDIT HERE>):
def filter(self, bmp_out: Addressable2D, bmp_in: Addressable2D):
height = bmp_in.get_height()
width = bmp_in.get_width()
if bmp_out.get_height() != height:
raise RuntimeError("Error in filter: input bitmaps differ in height")
if bmp_out.get_width() != width:
raise RuntimeError("Error in filter: input bitmaps differ in width")
for i_y in range(1, height - 1):
for i_x in range(1, width - 1):
new_value = [0 for _ in range(3)]
for rgb in range(3):
val = <EDIT HERE> # we simply take the arithmetic mean of the point and its 8 direct neighbors
new_value[rgb] = round(val)
bmp_out.set_at(i_x, i_y, Pixel(*new_value))
smoother = DirectNeighborSmoother()
if __name__ == "__main__":
bmp = Bitmap("PTBcolor.bmp")
print("Dims of bitmap: ({},{})".format(bmp.width, bmp.height))
# Test the naive implementation against the PIL library version
# this is for comparison
pil_img = Image.open("PTBcolor.bmp")
pil_img_arr = np.array(pil_img)
for i in range(bmp.width):
for j in range(bmp.height):
for rgb in range(3):
pil_pixel = pil_img.getpixel((i, -j))[rgb]
my_pixel = int(bmp.get_pixel(i, -j)[rgb])
if pil_pixel != my_pixel:
print("Mismatch at index pair (x,y,c) = ({0}, {1}, {2}) : {3} != {4}".format(
i, j, rgb, pil_pixel, my_pixel))
# smooth the image by averaging over the pixel and its direct 8 neighbors
out_bitmap = Bitmap.from_dims(width=bmp.width, height=bmp.height)
<EDIT HERE> # call the filter here
# save this image (we use PIL here, otherwise we have to understand the bitmap format much deeper)
img_out = Image.new('RGB', (out_bitmap.width, out_bitmap.height), 'black')
pixels = img_out.load()
for i in range(0, out_bitmap.width):
for j in range(0, out_bitmap.height):
(r, g, b) = out_bitmap.get_pixel(i, j)
pixels[i, j] = (int(r), int(g), int(b))
img_out.save('PTBcolor_smoothed.bmp')
import random
# This example has been adapted from https://python-3-patterns-idioms-test.readthedocs.io/en/latest/Factory.html
class ShapeFactory:
factories = {}
@staticmethod
def add_factory(id, shape_factory):
ShapeFactory.factories[id] = shape_factory
@staticmethod
def create_shape(id):
if id not in ShapeFactory.factories.keys():
ShapeFactory.add_factory(id, eval(id + '.Factory()')) # <## MARK1 ##>
return ShapeFactory.factories[id].create()
class Shape(object):
pass
class Circle(Shape):
def draw(self):
print("Circle.draw")
def erase(self):
print("Circle.erase")
class Factory:
def create(self):
return Circle()
class Square(Shape):
def draw(self):
print("Square.draw")
def erase(self):
print("Square.erase")
class Factory:
def create(self):
return Square()
# what follows is the client code, we want to randomly create shape type objects
def shape_name_gen(n):
types = Shape.__subclasses__()
for i in range(n):
yield random.choice(types).__name__ # NOTE: This is the convention we have chosen, cf. above <## MARK1 ##>
shapes = [ShapeFactory.create_shape(i)
for i in shape_name_gen(5)]
for shape in shapes:
shape.draw()
shape.erase()
class OddIterator:
"""Iterator returning only odd integer numbers up to a certain max value N"""
def __init__(self, N):
self._N = N
self.num = 1
def __iter__(self):
return self
def __next__(self):
num = self.num
self.num += 2
if num <= self._N:
return num
else:
raise StopIteration
odds = OddIterator(5)
print(next(odds))
print(list(odds))
# print(next(iter(odds))) # NOTE: this will throw
odds2 = OddIterator(10)
for item in iter(odds2):
print(item)
0% Loading or .
You are about to add 0 people to the discussion. Proceed with caution.
Please register or to comment
